Jaw Parallel Gripper, Series Rth 3 MPN:RTH-5M-L
Jaw Parallel Gripper, Series Rth 3
The ROBOHAND Jaw Parallel Gripper, Series RTH 3, is a versatile and reliable solution for various industrial applications. This gripper's parallel jaw design enables it to hold objects securely, making it ideal for handling and processing tasks in manufacturing, assembly, and material handling. With a maximum operating pressure of 100 psi and a total rated grip force of 4,125 N, it can handle a wide range of objects. The gripper's durable aluminum body and carbon steel fingers ensure long-lasting performance, while its IP55 rating protects against dust and water. Suitable for use in temperatures ranging from -35°C to 80°C, this gripper is perfect for applications in various industries, including automotive, aerospace, and robotics.
Top product features:
- Open Width of 126 mm allows for gripping of objects up to 126 mm in width.
- Stroke Length of 26 mm enables the gripper to grasp and release objects with a precise movement.
- Maximum Operating Pressure of 100 psi allows for gripping and holding of objects with a high level of force.
Top product applications:
- Assembly of small electronic components
- Pick and place of fragile or delicate parts
- Material handling in industrial environments with limited space
Parallel Jaw Gripper, Series RTH, Open Width 126 mm, Stroke Length 26 mm, Maximum Operating Pressure 100 psi, Minimum Operating Pressure 29 psi, Overall Length 88 mm, Overall Width 126 mm, Overall Height 88 mm, Body Material Aluminum, Finger Material Carbon Steel, Inlet Size M5, Maximum Operating Temperature 80 Degrees C, Minimum Operating Temperature -35 Degrees C, Weight 3.9 kg, System of Measurement Metric, Total Rated Grip Force @ 100 psi 4,125 N, IP Rating IP55, Seal Material Buna-N
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
