Jaw Parallel Gripper, Series Rth 3 MPN:RTH-1M-L
Jaw Parallel Gripper, Series Rth 3
The ROBOHAND Jaw Parallel Gripper, Series RTH 3, is a robust and reliable component designed for various industrial applications. Its high grip force and precision allow for secure grasping and manipulation of small parts, making it ideal for pick-and-place operations, assembly, and testing. The gripper's aluminum body and carbon steel fingers ensure durability and resistance to wear, while its wide operating temperature range and IP55 rating guarantee reliable performance in demanding environments. Suitable for use in robotics, automation, and manufacturing, this gripper offers a reliable solution for handling small parts with precision and accuracy.
Top product features:
- Open Width 52 mm
- Stroke Length 8 mm
- Maximum Operating Pressure 100 psi
Top product applications:
- Automotive Industry: The Jaw Parallel Gripper can be used to assemble and disassemble components in tight spaces, such as in the manufacture of electric vehicle batteries.
- Aerospace Industry: The gripper's high operating pressure and precision design make it suitable for use in the assembly of small parts in the aerospace industry, such as in the production of satellite components.
- Robotics and Automation: The gripper's compact size and high grip force make it a good fit for use in robotic systems, where it can be used to pick and place small components in tight spaces.
Parallel Jaw Gripper, Series RTH, Open Width 52 mm, Stroke Length 8 mm, Maximum Operating Pressure 100 psi, Minimum Operating Pressure 29 psi, Overall Length 37 mm, Overall Width 52 mm, Overall Height 37 mm, Body Material Aluminum, Finger Material Carbon Steel, Inlet Size M3, Maximum Operating Temperature 80 Degrees C, Minimum Operating Temperature -35 Degrees C, Weight 0.25 kg, System of Measurement Metric, Total Rated Grip Force @ 100 psi 443 N, IP Rating IP55, Seal Material Buna-N
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 42 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on January 20, 2026 12:19am UTC
Category: Compressors, Air Tanks and Pneumatic Parts
