Parallel Gripper, Widebody, Directconnect MPN:DPW-375M-1
Parallel Gripper, Widebody, Directconnect
The ROBOHAND Parallel Gripper, Widebody, Directconnect is a high-performance gripping solution designed for industrial automation applications. Ideal for tasks such as pick-and-place, assembly, and material handling, this gripper features a wide open width of 122 mm and a stroke length of 25.4 mm, allowing for efficient and precise grasping of various objects. With a maximum operating pressure of 100 psi and a total rated grip force of 445 N, this gripper can handle a wide range of materials and applications, including robotics, packaging, and manufacturing. Its durable design and IP66 rating make it suitable for harsh environments.
Top product features:
- Open Width 122 mm allows for gripping a wide range of objects.
- Stroke Length 25.4 mm enables precise control over object movement.
- Maximum Operating Pressure 100 psi provides a strong grip force.
Top product applications:
- Assembly and manufacturing of small parts and components
- Material handling and transfer in automated systems
- Pick and place operations in robotics and automation applications
Parallel Gripper, Series DPW, Open Width 122 mm, Stroke Length 25.4 mm, Maximum Operating Pressure 100 psi, Minimum Operating Pressure 21.7 psi, Overall Length 54 mm, Overall Width 97 mm, Overall Height 54 mm, Body Material Aluminum, Finger Material Carbon Steel, Inlet Size M5, Maximum Operating Temperature 80 Degrees C, Minimum Operating Temperature -35 Degrees C, Weight 0.81 kg, System of Measurement Metric, Total Rated Grip Force @ 100 psi 445 N, IP Rating IP66, Seal Material Buna-N
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 14 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 5.00
Product info last updated on April 8, 2026 10:58pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
