HHIP 2″ Center Distance Precision Magnetic Sine Bar MPN:3800-5410
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2495816
HHIP 2″ Center Distance Precision Magnetic Sine Bar
The Pro-Series Permanent Magnetic Sine Bar is a precision tool designed for accurate angle measurements and layout. Its permanent magnetic design ensures secure attachment to metal surfaces, reducing the risk of movement or slippage. Ideal for use in machining, engineering, and quality control applications, this sine bar provides repeatable and reliable results. Its compact size and lightweight design make it easy to transport and store, while its durable construction ensures long-lasting performance. Whether you're working with small parts or complex assemblies, the Pro-Series Permanent Magnetic Sine Bar is a valuable addition to any workshop or production floor.
Top product features:
- Permanent magnetic attachment for secure positioning
- Sine bar design for precise angle measurement
- Precision-ground surface for accurate workpiece alignment
Top product applications:
- Precision measurement in machining and engineering applications
- Machine tool calibration and setup
- Quality control inspection in manufacturing
HHIP 2″ Center Distance Precision Magnetic Sine Bar PRECISION WORKHOLDING & INSPECTION - Features an integrated permanent magnet with 8 lbs. of holding force, designed specifically to secure precision gauge block stacks and light ferrous workpieces during surface plate layout and inspection without distorting delicate parts. HIGH-PRECISION ACCURACY - Ground to extreme tolerances, holding parallelism within 0.0001″ (0.003 mm) and squareness within 0.0002″ (0.005 mm) for reliable metrology setups. HARDENED TOOL STEEL CONSTRUCTION - Manufactured from premium hardened tool steel and heat-treated to HRC 56-68 for maximum durability, wear resistance, and long-term dimensional stability. MATCHED ROLLS - Feature a 2.00″ (50 mm) center-to-center distance with roll accuracy held within +0.00008″, ensuring exact angle calculations with standard sine tables. COMPACT METROLOGY DESIGN - 3″ overall length provides convenient handling on benchtop granite plates and layout setups.
Additional Information
- Country of Origin: TW
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.00
- Package Width: 1.00
- Package Height: 6.00
- Package Weight: 1.00
Product info last updated on February 18, 2026 7:55pm UTC
Category: Measuring and Marking Tools
