Quick Connect Socket, Brass, 1 5/8" L MPN:25SFAN10SXZ
The PARKER Quick Connect Socket is a reliable and efficient solution for pneumatic, hydraulic, and general fluid transfer applications. Its push-to-connect mechanism allows for rapid connection and disconnection without tools, reducing leakage and increasing productivity. Suitable for a wide range of industries, this socket is ideal for use in manufacturing, construction, and laboratory settings where quick and secure connections are essential. With its brass construction, nickel-plated finish, and aerodynamic internal valve, this socket provides a durable and leak-free connection, making it a valuable addition to any fluid transfer system.
Top product features:
- Push-to-connect mechanism allows rapid connection and disconnection without tools, reducing leakage compared to an uncoupled connection.
- The fitting is constructed primarily from brass with a nickel-plated finish, providing durability and corrosion resistance.
- The aerodynamic internal valve reduces leakage and improves flow rates, allowing for efficient fluid transfer.
Top product applications:
- Pneumatic applications
- Hydraulic applications
- General fluid transfer applications
The PARKER - 25SFAN10SXZ is a quick connect coupling female component designed for pneumatic, hydraulic, or general fluid transfer applications. It accepts and locks the matching plug with the specified ball-mechanism coupling design (includes four locking balls) to provide a sealed connection when installed with compatible components and within the specified pressure and temperature ranges. Featuring a push-to-connect mechanism with a spring-loaded release sleeve and an aerodynamic internal valve, it allows rapid connection and disconnection using the push-to-connect mechanism without tools, while reducing leakage compared to an uncoupled connection
- leakage rate depends on operating conditions and compatible installation. The fitting is compatible with European High Flow interchange standards (as specified by the product’s interchange requirements) and constructed primarily from brass with a nickel-plated finish.
Key Features:
- - Body size for air coupling: 1/4"
- - Connection type: 1/8"-27 NPTF thread
- - Hose fitting size: 1/8 in, male gender
- - Coupling locking type: Ball mechanism
- - Includes valve: Yes, aerodynamic type
- - Seal material: Nitrile
- - Maximum flow rate: 110 scfm
- - Maximum working pressure: 300 psi at 70°F
- - Operating temperature range: -4°F to 212°F
- - Overall length: 1.63 in (1 5/8 in)
- - Includes four locking balls
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 20 days
- Minimum Order Quantity: 10
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 3.00
- Package Height: 3.00
- Package Weight: 0.40
