Quick Connect Socket, Steel, 1 7/16" L MPN:25SFIN13SXZ

The PARKER - 25SFIN13SXZ is a quick connect socket designed as the female half of a quick‑connect coupling system. The socket provides a push-to-connect connection using a ball locking mechanism for hookup and disconnection. Manufactured from steel with a zinc-plated finish, this socket is compatible with European High Flow interchange standards and connects to 1/4" hoses or fittings via a 1/4"-18 NPTF threaded connection. It is rated for operation within a temperature range of -4°F to 212°F and has a maximum working pressure of 300 psi (at 70°F as specified).

Key Features:

• - Body size and hose fitting size: 1/4 inch
• - Connection type: Female, 1/4"-18 NPTF thread
• - Locking mechanism: Ball type
• - Material: Steel with zinc plating finish
• - Seal material: Nitrile
• - Maximum working pressure: 300 psi at 70°F
• - Overall length: 1.44 inches
• - Maximum outside diameter: 0.75 inches
• - Valve type: Aerodynamic
• - Interchange type: European High Flow
• - Includes four locking balls
• - Temperature range: -4°F to 212°F
• - Does not include an integrated valve for shut-off or check flow control
