Coupler Plug, Steel, 3/8 In. Pipe, 110 cfm MPN:H1F
Boost your pneumatic system's efficiency with the Parker H1F Coupler Plug! This reliable steel coupler connects and disconnects quickly and securely using a push/pull locking mechanism, making it perfect for applications in the manufacturing, automotive, and construction industries. With a maximum working pressure rating of 300 psi and a temperature range of -40°F to 250°F, it can withstand even the toughest conditions. Its compact design and ease of use make it an ideal choice for repetitive tasks, reducing downtime and increasing productivity. Upgrade to the Parker H1F Coupler Plug for a seamless and efficient pneumatic system experience.
Top product features:
- Connects and disconnects using a push/pull locking mechanism.
- Rated for operation in the temperature range of -40°F to 250°F.
- Has a maximum working pressure rating of 300 psi.
Top product applications:
- Pneumatic
- Pneumatic applications
- Industrial
The PARKER - H1F is a quick connect hose coupling for pneumatic applications. Constructed from steel with a trivalent chrome finish
- connects and disconnects using a push/pull locking mechanism. It is rated for operation in the temperature range of -40°F to 250°F and has a maximum working pressure rating of 300 psi, has a maximum flow rate rating of 3,114.85 liters per minute.
Key Features:
- - Application: Pneumatic
- - Connection type: NPT thread with a thread size of 3/8"-18
- - Material: Steel with trivalent chrome coating
- - Hose fitting gender: Female
- - Body/ Coupling size: 1/2 in
- - Hose fitting size: 3/8 in
- - Maximum flow rate: 3,114.85 lpm
- - Maximum working pressure rating is 300 psi at 70°F
- - Maximum outside diameter: 15/16 in
- - Overall length: 2.06 in
- - Temperature range: -40°F to 250°F
- - Interchange type: Industrial
- - Barbed: No
- - Includes valve: No
