Valve, Air Pilot, 3 Way, 1 In Inlet MPN:N37471091
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0772405
Valve, Air Pilot, 3 Way, 1 In Inlet
This 3-way pilot air control valve from Parker is a reliable solution for regulating air flow in various industrial applications. With a maximum operating pressure of 140 psi and a pilot pressure of 25 psi, it can handle demanding conditions. Its compact design, measuring 4 1/16 x 4 19/50 x 5 9/16 inches, makes it ideal for use in tight spaces. This valve is suitable for applications such as pneumatic systems, air compressors, and industrial machinery, providing precise control and efficient air flow management. Its durability and reliability make it a valuable addition to any industrial setup.
Top product features:
- The valve is a 3-way/2-position pilot air control valve, allowing for control of air flow in multiple positions.
- The valve has a 1 1/4 in outlet and a 1 in inlet, enabling efficient air flow through the system.
- The valve is designed to operate at a maximum of 140 psi, providing reliable performance in high-pressure applications.
Top product applications:
- Air Compressor Control System
- Automotive Air Brake System
- Industrial Air Supply System
Pilot Air Control Valve, Valve Ways and Positions 3-Way/2-Position, Valve Actuator / Return Air Pilot / Air Return, Valve Port Size 1 1/4 in Outlet, 1 in Inlet, Max. CFM - Valves 11 cfm, Center Position Not Applicable, Max. Operating PSI 140 psi, Pilot Pressure 25 psi, Pilot Port Size NPT (In.) 1/4, Max. Temp. Range (F) 0 to 125, Vacuum External Pilot, Coefficient of Volume 9.3, Cycles per Minute -, Length (In.) 4 1/16 in, Width (In.) 4 19/50 in, Height (In.) 5 9/16 in
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.20
- Package Width: 6.40
- Package Height: 4.70
- Package Weight: 2.90
Product info last updated on March 30, 2026 11:47pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
