Electric Hydraulic Press, 10 Ton, Small Benchtop Shop Press MPN:9661612

• The PALMGREN 9661612 Hydraulic Press is a 10-ton electric-powered H-frame press designed for bending, forming, clamping, punching, staking, and straightening operations. It operates using a single-phase, 230V hydraulic system with a 3 hp motor and a 2-gallon reservoir. The press has a bolted iron frame with a fixed, single-acting cylinder that provides consistent force through a 6-1/4 inch stroke. It includes table plates and V-blocks for setup flexibility.

  Key Features:

  • - Press Type: Electric hydraulic H-frame press
  • - Capacity: 10 ton
  • - Cylinder Type: Single-acting fixed hydraulic cylinder
  • - Stroke Length: 6-1/4 in
  • - Pump Type: Hydraulic electric with 3 hp motor
  • - Frame Material: Iron with bolted channel design
  • - Voltage: 230V, single phase
  • - Reservoir Capacity: 2 gal
  • - Working Width: 19-1/4 in
  • bed width 19-1/4 in
  • bed depth 6-5/8 in
  • - Ram-to-Table Distance: 7-5/8 in minimum to 18-1/8 in maximum
  • - Overall Dimensions: 80 in H × 40 in W × 30 in D
  • - Includes: Table plates and V-blocks
  • - Applications: Bending, clamping, forming, pressing bearings, punching, staking, and straightening
