Capacitive, Cylindrical Proximity Sensor, 18 mm Dia., Plastic, 2 m, Bare Wire, 2 Wires, Unshielded MPN:E2K-X8MY2
Capacitive, Cylindrical Proximity Sensor, 18 mm Dia., Plastic, 2 m, Bare Wire, 2 Wires, Unshielded
This capacitive proximity sensor is a compact and reliable solution for detecting objects in various applications. Its cylindrical shape and 18mm diameter make it ideal for use in tight spaces and automated systems. With a detection distance of 8mm and a maximum current load of 200mA, it can be used in a range of applications, including industrial automation, robotics, and material handling. The sensor's operating temperature range of -13°F to 158°F and IP66 rating ensure it can withstand harsh environments. Its 2m cable and 2-wire output make it easy to integrate into existing systems.
Top product features:
- Capacitive sensing technology allows for detection of objects without physical contact
- Detects objects up to 8 mm away
- Operates within a temperature range of -13 to 158 degrees Fahrenheit
Top product applications:
- Automotive parts inspection
- Material handling and automation
- Robotics and machine vision
Capacitive Cylindrical Proximity Sensor, Capacitive, 18 mm, Proximity Sensor Power Requirement 90 to 250V AC, Unshielded, Proximity Sensor Operating Frequency 10 Hz, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 8 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NC, NEMA Rating 1, 12, 13, 4, IP Rating IP66, Case Material ABS, Length 41 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
Additional Information
- Country of Origin: JP
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 4.40
- Package Height: 2.70
- Package Weight: 0.35
Product info last updated on January 13, 2026 11:54am UTC
Category: Industrial Electrical Controls and Automation
