Cylindrical, Inductive Proximity Sensor, 18 mm Dia., Stainless Steel, M12, 2 Wires, Shielded MPN:E2E-X5Y1-M1
Cylindrical, Inductive Proximity Sensor, 18 mm Dia., Stainless Steel, M12, 2 Wires, Shielded
The Omron Cylindrical Inductive Proximity Sensor is a reliable and versatile solution for detecting metal objects in various industrial applications. Its stainless steel design and IP67 rating ensure durability and resistance to harsh environments. With a detection range of up to 5mm and a frequency of 25Hz, this sensor is ideal for use in conveyor systems, robotics, and automation. Its compact size and 2-wire output make it easy to integrate into existing systems. Suitable for use in temperatures ranging from -40 to 185°F, this sensor provides accurate and consistent detection, making it a valuable asset for industrial operations.
Top product features:
- Cylindrical shape allows for easy installation in tight spaces
- Inductive technology detects metal objects without physical contact
- Shielded design minimizes electromagnetic interference
Top product applications:
- Automotive applications due to its high temperature range and IP67 rating
- Medical equipment due to its stainless steel and nickel plated brass construction
- Industrial automation due to its high frequency and current load capabilities
Inductive Cylindrical Proximity Sensor, Inductive, 18 mm, Proximity Sensor Power Requirement 24 to 240V AC, Shielded, Proximity Sensor Operating Frequency 25 Hz, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 5 mm, Proximity Sensor Electrical Connection 4 Pin M12 Connector, Output Mode NO, NEMA Rating 4X, IP Rating IP67, Case Material Nickel Plated Brass, Length 41 mm, Operating Temp. Range -40 Degrees to 185 Degrees F, Max. Current Load 300mA
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 3.00
- Package Height: 1.00
- Package Weight: 0.15
Product info last updated on January 13, 2026 2:01pm UTC
Category: Industrial Electrical Controls and Automation
