W-Bracket, Enclosed Power Relay, Square, 25 A, 10 Pins, Quick Connect MPN:G7J-3A1B-T-W1-DC24
W-Bracket, Enclosed Power Relay, Square, 25 A, 10 Pins, Quick Connect
The Omron W-Bracket Enclosed Power Relay is a versatile and reliable solution for a wide range of applications, including industrial automation, robotics, and medical equipment. Its square base shape and quick-connect terminals make it easy to integrate into existing systems, while its 25A current rating and 3PST-NO/SPST-NC contact form provide robust switching capabilities. The relay's semi-sealed design and push-to-test method ensure safe and efficient operation, making it suitable for use in harsh environments. With its high horsepower rating and compact design, this relay is ideal for applications requiring high power switching in a small footprint.
Top product features:
- Enclosed design protects electrical components from the environment
- Quick Connect electrical connection allows for easy attachment and detachment of wires
- Three-position, single-pole, single-throw (3PST-NO, SPST-NC) contact form enables switching of loads in three different configurations
Top product applications:
- Industrial Control Systems
- Automotive Electronics
- Medical Device Control Panels
Enclosed Power Relay, Base Shape Square, Coil Voltage 24V DC, Contact Form 3PST-NO, SPST-NC, Current Rating 25 A, Electrical Connection Quick-Connect, Flat Pin Width 0.031 in, Number of Pins 10, Sealing Semi-Sealed, Status Indicator No Indicator, Contact Rating (AC) 25 A @ 240V (NO), 8 A @ 240V (NC), Contact Rating (DC) 25 A @ 30V (NO), 8 A @ 30V (NC), Horsepower @ 120V AC 1 1/2 hp, Horsepower @ 240V AC 3 hp, Mounting Style W-Bracket, Push-To-Test Method Push Button, Body Depth 2.15 in
Additional Information
- Country of Origin: JP
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 70 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.20
- Package Width: 6.50
- Package Height: 4.80
- Package Weight: 0.70
Product info last updated on February 10, 2026 3:08pm UTC
Category: Industrial Electrical Controls and Automation
