Capacitive, Cylindrical Proximity Sensor, 18 mm Dia., Plastic, 2 m, Bare Wire, 3 Wires, Unshielded MPN:E2K-X8ME1
Capacitive, Cylindrical Proximity Sensor, 18 mm Dia., Plastic, 2 m, Bare Wire, 3 Wires, Unshielded
This Omron capacitive proximity sensor is a reliable and versatile solution for detecting objects within a 8mm range. Its cylindrical design and 18mm diameter make it easy to integrate into a variety of applications, including industrial automation, material handling, and robotics. With a wide operating temperature range and high current load capacity, this sensor can withstand harsh environments and demanding usage. Its compact size and unshielded design also make it ideal for use in applications where space is limited. Suitable for use in food processing, pharmaceuticals, and other industries where cleanliness is paramount.
Top product features:
- Capacitive sensing technology allows the sensor to detect objects without physical contact.
- The sensor has a maximum detecting distance of 8 mm, enabling precise detection of objects at close range.
- The sensor has a 3-wire NPN output circuit, providing a standardized interface for connection to external devices.
Top product applications:
- Automotive applications
- Industrial automation
- Medical device manufacturing
Capacitive Cylindrical Proximity Sensor, Capacitive, 18 mm, Proximity Sensor Power Requirement 10 to 30V DC, Unshielded, Proximity Sensor Operating Frequency 100 Hz, Proximity Sensor Output Circuit Type 3 Wire NPN, Max. Detecting Distance 8 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NO, NEMA Rating 1, 12, 13, 4, IP Rating IP66, Case Material Plastic, Length 41 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
Additional Information
- Country of Origin: JP
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.40
- Package Width: 4.40
- Package Height: 2.60
- Package Weight: 0.50
Product info last updated on February 21, 2026 4:41pm UTC
Category: Industrial Electrical Controls and Automation
