3 Mount Holes, Flange Bracket, Flange Mount Bearing, Radial Ball, 63/64 in Dia, Stainless Steel, Set Screw Locking MPN:SUCFB205CCFG1
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G6581925
3 Mount Holes, Flange Bracket, Flange Mount Bearing, Radial Ball, 63/64 in Dia, Stainless Steel, Set Screw Locking
This 3 Bolt Flange Bearing from NTN is a reliable and durable solution for various industrial applications. Its stainless steel construction and double sealed design ensure long-lasting performance in harsh environments, while its radial ball bearing insert provides smooth and quiet operation. Suitable for use in food processing, pharmaceutical, and other sanitary applications, this bearing can withstand temperatures from -20 to 120 degrees C and speeds up to 5,100 RPM. Its compact design and fixed expansion type make it an ideal choice for space-constrained installations, such as pumps, mixers, and conveyor systems.
Top product features:
- Double Sealed Closure
- Fixed Expansion Type
- FDA/USDA-H1 Solid Grease Lubrication
Top product applications:
- Automotive applications, such as in engine components or suspension systems, where the bearing's high temperature and speed ratings are beneficial.
- Food processing equipment, like mixers or conveyor belts, where the FDA/USDA-H1 solid grease meets sanitary requirements.
- Industrial machinery, such as gearboxes or pumps, where the bearing's fixed expansion and double sealed design provide long-lasting performance.
3 Bolt Flange Bearing, Back Side to Center Width 16 mm, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 25 mm, Bore Type Cylindrical, Closure Double Sealed, Expansion Type Fixed, Housing Material Stainless Steel, Housing Type Flange Bracket, Included Bearing SUC205, Lubricant Material FDA/USDA-H1 Solid Grease, Maximum Speed 5,100 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -20 Degrees C, Mount Hole Center-to-Center Height 41.4 mm
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.30
- Package Width: 3.40
- Package Height: 2.00
- Package Weight: 1.55
Product info last updated on March 1, 2026 1:54am UTC
Category: Bearings, V-belts and Power Transmission Equipment
