Angular Contact Bearing, 20mm, OD 47mm, PK2 MPN:7204CG1DUJ74
Angular Contact Bearing, 20mm, OD 47mm, PK2
This angular contact bearing from NTN is designed for high-speed applications, with a maximum speed of 25,500 RPM and a temperature range of -40 to 120°C. Its 20mm bore diameter and 47mm outside diameter make it suitable for a variety of industrial uses, including machinery and equipment. The bearing's alloy steel construction and stratified cage ensure durability and reliability. Ideal for use in demanding environments, this bearing is perfect for applications in the aerospace, automotive, and industrial sectors, where precision and performance are crucial. Its compact size and high-speed capabilities make it an excellent choice for many industries.
Top product features:
- Angular Contact Ball Bearing with a 15-degree contact angle for high precision and smooth operation in applications with radial and axial loads.
- Made with alloy steel for high strength and durability in demanding environments.
- Features a stratified cage design for improved load capacity and reduced vibration.
Top product applications:
- High-speed machinery such as turbine engines
- Industrial gearboxes
- Aerospace applications
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 7204, Bore Diameter 20 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 25,500 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 47 mm, Overall Width 14 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.40
- Package Width: 2.40
- Package Height: 1.50
- Package Weight: 0.48
Product info last updated on February 9, 2026 6:18pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
