Cylindrical BRG, Double Row, Bore 65mm MPN:NN3013KC1NAP4
Cylindrical BRG, Double Row, Bore 65mm
This cylindrical roller bearing from NTN is designed for high-performance applications, featuring a tapered bore and alloy steel construction for maximum durability. With a maximum speed of 6,200 RPM grease or 7,300 RPM oil, it's ideal for use in heavy-duty industrial machinery, such as gearboxes, pumps, and motors. The open design allows for easy lubrication and maintenance, while the brass cage provides smooth roller movement. Its wide temperature range (-40 to 120°C) makes it suitable for use in harsh environments. Applications include textile machinery, conveyor systems, and power transmission equipment.
Top product features:
- Tapered bore allows for easy mounting and dismounting of the bearing.
- Double row design provides increased load carrying capacity and stability.
- Alloy steel construction enables high strength and durability.
Top product applications:
- Heavy Duty Industrial Machinery
- High-Speed Spindle Applications
- High-Temperature Industrial Equipment
Cylindrical Roller Bearing, Bearing Industry Number 3013, Bore Diameter 65 mm, Bore Type Tapered 1:12, Cage Material Brass, Closure Open, Inner Ring Outside Diameter 71.5 mm, Lubricant Material Grease, Oil, Maximum Speed 6,200 RPM Grease, 7,300 RPM Oil, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows Two, Outer Ring Inside Diameter 92 mm, Outside Diameter 100 mm, Overall Width 26 mm, Ring Material Alloy Steel, Roller Material Alloy Steel
Additional Information
- Country of Origin: JP
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.60
- Package Width: 4.60
- Package Height: 2.50
- Package Weight: 1.75
Product info last updated on February 28, 2026 10:37am UTC
Category: Bearings, V-belts and Power Transmission Equipment
