Angular Contact Bearing, 45mm, OD 75mm, PK2 MPN:7009CVDUJ74
Angular Contact Bearing, 45mm, OD 75mm, PK2
This high-performance Angular Contact Bearing from NTN is designed for demanding applications that require precise positioning and high-speed operation. With a contact angle of 15 degrees and a maximum speed of 14,600 RPM, it's ideal for use in industrial machinery, automotive systems, and aerospace equipment. Its alloy steel construction and stratified cage ensure reliable performance in temperatures ranging from -40°C to 120°C. Suitable for duplex matched bearing applications, this bearing provides smooth, quiet operation and extended lifespan, making it a valuable component in a variety of industries, including manufacturing, robotics, and power generation.
Top product features:
- Angular Contact Bearing design allows for high-speed operation up to 14,600 RPM.
- The bearing has a 15-degree contact angle, enabling precise alignment and smooth motion.
- The bearing features a stratified cage design for improved load-carrying capacity and reduced vibration.
Top product applications:
- Machine Tool Spindles
- High-Speed Industrial Equipment
- Aerospace Applications
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 7009, Bore Diameter 45 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 14,600 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 75 mm, Overall Width 16 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 3.25
- Package Width: 3.25
- Package Height: 2.00
- Package Weight: 1.11
