Angular Contact Bearing, 30mm, OD 55mm, PK2 MPN:7006CVDUJ74
Angular Contact Bearing, 30mm, OD 55mm, PK2
The NTN Angular Contact Bearing is a high-performance bearing designed for demanding applications. With a 30mm bore diameter and 55mm outside diameter, it offers a compact yet robust solution for precise angular contact. Its alloy steel construction and stratified phenolic cage ensure high rigidity and durability. Suitable for use in high-speed and high-temperature environments, this bearing can operate at up to 20,800 RPM and temperatures up to 120°C. Ideal for industrial applications such as gearboxes, pumps, and motors, this bearing provides reliable performance and long lifespan. Its compact size makes it an excellent choice for space-constrained designs.
Top product features:
- Angular Contact Bearing design allows for high precision and smooth operation in demanding applications.
- Ball material is Alloy Steel, providing high strength and durability.
- Cage material is Phenolic, allowing for high-temperature operation.
Top product applications:
- Industrial machinery
- Automotive applications
- Aerospace equipment
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 7006, Bore Diameter 30 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 20,800 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 55 mm, Overall Width 13 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.40
- Package Width: 2.40
- Package Height: 1.50
- Package Weight: 0.53
Product info last updated on March 7, 2026 10:49am UTC
Category: Bearings, V-belts and Power Transmission Equipment
