Ball Screw Support Bearing, Bore 35mm MPN:BST35X72-1BP4
Ball Screw Support Bearing, Bore 35mm
The NTN Ball Screw Support Bearing is a high-performance bearing designed for use in ball screw applications where high precision and reliability are critical. Its alloy steel construction and angular contact design ensure smooth, quiet operation and long bearing life. With a temperature range of -40 to 120°C, this bearing can withstand demanding environments. Ideal for use in machine tools, CNC machines, and other precision machinery, it provides precise motion control and reduced vibration. The bearing's compact size and lightweight design make it easy to integrate into existing systems, making it a versatile and reliable choice for a wide range of applications.
Top product features:
- Ball Screw Support Bearing provides angular contact for precise movement and support.
- The bearing features a 60-degree contact angle for improved load-carrying capacity.
- The alloy steel ball material ensures high durability and resistance to wear.
Top product applications:
- Machine Tool Spindles
- Robotics and Automation Systems
- Precision Linear Motion Systems
Ball Screw Support Bearing, Ball Material Alloy Steel, Bearing Industry Number 35X72, Bore Diameter 35 mm, Cage Material Nylon, Closure Open, Contact Angle 60 Degrees , Contact Bearing Type Angular Contact, Lubricant Material Oil, Matched Bearing Type Not Matched/Single Bearing, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 72 mm, Overall Width 15 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7
Additional Information
- Country of Origin: JP
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.00
- Package Width: 0.80
- Package Height: 3.00
- Package Weight: 0.65
