Angular Contact Bearing, 25mm, OD 42mm, PK2 MPN:71905CVDUJ74
Angular Contact Bearing, 25mm, OD 42mm, PK2
This high-performance Angular Contact Bearing from NTN is designed for demanding applications where precision and reliability are crucial. With a contact angle of 15 degrees and a maximum speed of 26,000 RPM, it excels in high-speed and high-load situations. Suitable for use in industrial machinery, aerospace, and automotive applications, this bearing provides smooth operation and extended lifespan. Its alloy steel construction and phenolic cage ensure durability and resistance to temperature fluctuations. Whether in harsh environments or high-precision machinery, this bearing delivers exceptional performance and reliability, making it an ideal choice for industries requiring precision and efficiency.
Top product features:
- Ball Material Alloy Steel provides high strength and durability
- Contact Angle 15 Degrees enables high-speed and precise applications
- Phenolic Cage Material offers corrosion resistance and improved bearing life
Top product applications:
- High-Speed Spindle Applications
- High-Torque Motor Applications
- Precision Machine Tool Applications
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 71905, Bore Diameter 25 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 26,000 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 42 mm, Overall Width 9 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.40
- Package Width: 2.40
- Package Height: 1.50
- Package Weight: 0.21
Product info last updated on February 12, 2026 4:28pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
