Cylindrical BRG, Double Row, Bore 90mm MPN:NN3018KC1NAP4
Cylindrical BRG, Double Row, Bore 90mm
The NTN Cylindrical BRG Double Row Bearing is a high-performance bearing designed for heavy-duty applications. Its 90mm bore diameter and 2-row configuration provide exceptional load-carrying capacity, making it ideal for use in industrial machinery, gearboxes, and other high-stress environments. The bearing's brass cage and alloy steel construction ensure durability and resistance to wear, while its grease or oil lubrication options provide long-lasting performance. With a maximum speed of 5,300 RPM and operating temperatures ranging from -40°C to 120°C, this bearing is suitable for a wide range of applications, including textile machinery, conveyor systems, and power transmission equipment.
Top product features:
- Cylindrical roller bearing design allows for high radial load capacity
- Double row configuration provides increased load support and stability
- Tapered bore design enables easy mounting and dismounting of the bearing
Top product applications:
- Heavy Industrial Equipment
- High-Speed Machines
- Power Generation Systems
Cylindrical Roller Bearing, Bearing Industry Number 3018, Bore Diameter 90 mm, Bore Type Tapered 1:12, Cage Material Brass, Closure Open, Inner Ring Outside Diameter 98 mm, Lubricant Material Grease, Oil, Maximum Speed 4,500 RPM Grease, 5,300 RPM Oil, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows Two, Outer Ring Inside Diameter 129 mm, Outside Diameter 140 mm, Overall Width 37 mm, Ring Material Alloy Steel, Roller Material Alloy Steel
Additional Information
- Country of Origin: JP
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.20
- Package Width: 6.20
- Package Height: 3.30
- Package Weight: 4.75
Product info last updated on May 4, 2026 6:39pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
