Angular Contact Bearing, 20mm, OD 37mm, PK2 MPN:71904CVDUJ74
Angular Contact Bearing, 20mm, OD 37mm, PK2
The NTN 20mm Angular Contact Bearing is a high-performance bearing designed for demanding applications. With a contact angle of 15 degrees, it provides precise load distribution and smooth operation. Suitable for use in high-speed machinery, the bearing's maximum speed of 31,200 RPM and temperature range of -40 to 120 degrees C make it ideal for applications in the aerospace, automotive, and industrial sectors. Its duplex design and stratified cage ensure reliable operation and long lifespan. Perfect for use in gearboxes, motors, and other high-torque equipment, this bearing delivers exceptional performance and durability in a compact 37mm package.
Top product features:
- Angular Contact Bearing design allows for high precision and stability in applications where radial and axial loads are present.
- The bearing has a 15-degree contact angle, enabling it to support both radial and thrust loads.
- The bearing is designed as a duplex type, allowing for the use of two bearings in a single housing to increase load capacity and reduce vibration.
Top product applications:
- High-speed machinery
- Industrial gearboxes
- Aerospace applications
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 71904, Bore Diameter 20 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 31,200 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 37 mm, Overall Width 9 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.40
- Package Width: 2.40
- Package Height: 1.50
- Package Weight: 0.19
Product info last updated on March 27, 2026 2:29pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
