Angular Contact Bearing, 15mm, OD 32mm, PK2 MPN:CH7002CVDUJ74[R1DE]
Angular Contact Bearing, 15mm, OD 32mm, PK2
This high-performance Angular Contact Bearing from NTN is designed for demanding applications that require precision and reliability. With a ceramic ball material and phenolic cage, this bearing provides exceptional durability and resistance to corrosion and wear. Its 15-degree contact angle and duplex matched bearing type make it ideal for use in high-speed and high-temperature environments, such as in aerospace, industrial machinery, and automotive applications. The bearing's compact size and lightweight design make it suitable for use in a wide range of industries, including robotics, medical devices, and renewable energy systems.
Top product features:
- Ceramic ball material for improved durability and resistance to corrosion
- Phenolic cage material for reduced noise and vibration
- 15-degree contact angle for increased load-carrying capacity and precision
Top product applications:
- Aerospace applications due to its high speed and temperature capabilities
- Industrial machinery such as gearboxes and pumps where high precision is required
- Automotive applications such as transmissions and engine mounts where high performance is needed
Angular Contact Ball Bearing, Ball Material Ceramic, Bearing Industry Number 7002, Bore Diameter 15 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 37,400 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 32 mm, Overall Width 18 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.40
- Package Width: 2.40
- Package Height: 1.50
- Package Weight: 0.16
Product info last updated on February 3, 2026 6:08pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
