Angular Contact Bearing, 25mm, OD 47mm, PK2 MPN:CH7005CVDUJ74
Angular Contact Bearing, 25mm, OD 47mm, PK2
The NTN Angular Contact Bearing, 25mm, OD 47mm, PK2 is a high-performance bearing designed for demanding applications. Its ceramic ball material and alloy steel ring provide exceptional durability and resistance to corrosion. With a contact angle of 15 degrees and a maximum speed of 31,800 RPM, this bearing is ideal for use in high-speed machinery, such as aerospace and industrial equipment. Its operating temperature range of -40 to 120 degrees C makes it suitable for use in a variety of environments. The bearing's compact design and low friction make it an excellent choice for use in precision instruments and medical devices.
Top product features:
- Ceramic ball material for improved wear resistance
- 15-degree contact angle for increased load carrying capacity
- Stratified cage design for reduced friction and improved bearing life
Top product applications:
- High-precision machine tools
- Industrial gearboxes
- Aerospace applications
Angular Contact Ball Bearing, Ball Material Ceramic, Bearing Industry Number 7005, Bore Diameter 25 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 31,800 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 47 mm, Overall Width 12 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.20
- Package Width: 1.30
- Package Height: 2.20
- Package Weight: 0.35
Product info last updated on February 6, 2026 11:07pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
