Angular Contact Bearing, 30mm, OD 47mm, PK2 MPN:71906CVDUJ74
Angular Contact Bearing, 30mm, OD 47mm, PK2
The NTN 71906 Angular Contact Bearing is a high-performance bearing designed for demanding applications. With a contact angle of 15 degrees and a maximum speed of 22,900 RPM, this bearing is ideal for use in high-speed machinery and equipment. Its alloy steel construction and phenolic cage provide exceptional durability and resistance to extreme temperatures. Suitable for use in industrial applications such as gearboxes, motors, and pumps, this bearing offers improved efficiency, reduced vibration, and increased lifespan. Its compact size and lightweight design make it a versatile choice for a wide range of industries.
Top product features:
- Angular contact bearing design allows for high precision and smooth operation in applications with high radial and axial loads.
- The bearing has a 15-degree contact angle, enabling it to accommodate both radial and thrust loads.
- The bearing is designed as a duplex type, allowing for two bearings to be used in a single housing to support high axial loads.
Top product applications:
- High-speed industrial machinery
- Automotive transmissions
- Aerospace applications
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 71906, Bore Diameter 30 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 22,900 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 47 mm, Overall Width 9 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.30
- Package Width: 1.10
- Package Height: 2.30
- Package Weight: 0.25
Product info last updated on March 5, 2026 5:10am UTC
Category: Bearings, V-belts and Power Transmission Equipment
