Angular Contact Bearing, 30mm, OD 55mm, PK2 MPN:ML7006CVDUJ74S
Angular Contact Bearing, 30mm, OD 55mm, PK2
This high-performance Angular Contact Bearing from NTN is designed for demanding applications where precision and reliability are crucial. With a 17-degree contact angle and a maximum speed of 30,000 RPM, it can handle high-speed operations with ease. Its alloy steel construction and phenolic cage ensure durability and resistance to extreme temperatures (-40°C to 120°C). Ideal for use in industrial machinery, automotive systems, and aerospace equipment, this bearing provides smooth operation and extended lifespan. Its compact design and low-friction properties make it an excellent choice for applications where space and efficiency are paramount, including gearboxes, motors, and pumps.
Top product features:
- Ball Material Alloy Steel provides high strength and durability
- 17 Degrees Contact Angle allows for increased load capacity and reduced vibration
- Cage Material Phenolic enables smooth and quiet operation
Top product applications:
- High-speed industrial machinery
- Automotive gearboxes and transmissions
- Power tools and machinery
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 7006, Bore Diameter 30 mm, Cage Material Phenolic, Closure Open, Contact Angle 17 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 30,000 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 55 mm, Overall Width 13 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 2.50
- Package Width: 2.50
- Package Height: 1.60
- Package Weight: 0.55
Product info last updated on March 29, 2026 11:35pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
