Angular Contact Bearing, 50mm, OD 72mm, PK2 MPN:71910CVDUJ74
Angular Contact Bearing, 50mm, OD 72mm, PK2
The NTN 50mm Angular Contact Bearing is a high-performance bearing designed for demanding applications. With its 15-degree contact angle and duplex matched bearing type, it provides smooth operation and long lifespan. Suitable for use in high-speed and high-temperature environments, this bearing can withstand temperatures from -40°C to 120°C and speeds up to 14,600 RPM. Ideal for use in industrial machinery, automotive applications, and aerospace equipment, this bearing offers improved efficiency and reduced maintenance. Its compact size and lightweight design make it easy to integrate into a wide range of systems and machines.
Top product features:
- Angular Contact Bearing design allows for high precision and stability in applications with high radial and axial loads.
- The bearing's 15-degree contact angle enables it to support both radial and thrust loads, making it suitable for use in applications where both types of loads are present.
- The bearing's alloy steel ball material provides high hardness and resistance to wear and corrosion, resulting in longer bearing life and reduced maintenance.
Top product applications:
- Industrial machinery such as pumps and gearboxes
- Automotive applications including transmissions and differentials
- High-speed equipment including turbines and centrifuges
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 71910, Bore Diameter 50 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 14,600 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 72 mm, Overall Width 12 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 3.25
- Package Width: 3.25
- Package Height: 2.00
- Package Weight: 0.69
Product info last updated on January 27, 2026 2:26pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
