Angular Contact Bearing, 40mm, OD 62mm, PK2 MPN:71908CVDUJ74
Angular Contact Bearing, 40mm, OD 62mm, PK2
The NTN 40mm Angular Contact Bearing is a high-performance bearing designed for demanding applications. With a contact angle of 15 degrees and a maximum speed of 17,200 RPM, it's ideal for use in high-speed machinery and equipment. The bearing's alloy steel construction and phenolic cage ensure durability and reliability, while its open design allows for easy maintenance and inspection. Suitable for use in automotive, industrial, and aerospace applications, this bearing is a reliable choice for any high-performance system, providing smooth operation and extended lifespan in temperatures ranging from -40°C to 120°C.
Top product features:
- Angular Contact Bearing design allows for high precision and smooth operation in applications with high radial and axial loads.
- The bearing's 15-degree contact angle enables it to withstand heavy loads and maintain accurate positioning.
- The bearing's alloy steel material and stratified cage design provide high strength and durability.
Top product applications:
- High-speed machinery
- Aerospace applications
- Industrial gearboxes
Angular Contact Ball Bearing, Ball Material Alloy Steel, Bearing Industry Number 71908, Bore Diameter 40 mm, Cage Material Phenolic, Closure Open, Contact Angle 15 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Duplex, Maximum Speed 17,200 RPM, Maximum Temperature 120 Degrees C, Minimum Temperature -40 Degrees C, Number of Rows One, Outside Diameter 62 mm, Overall Width 12 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 7, Cage Type Stratified
Additional Information
- Country of Origin: DE
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: PK
- Package Length: 3.50
- Package Width: 3.40
- Package Height: 2.10
- Package Weight: 0.50
Product info last updated on February 2, 2026 7:51am UTC
Category: Bearings, V-belts and Power Transmission Equipment
