2 Mount Holes, Rhombus, 2 Bolt Flange Bearing, Radial Ball, 1-1/4 in Dia, Stainless Steel, Set Screw Locking MPN:SUCFL206-20CCFG1
2 Mount Holes, Rhombus, 2 Bolt Flange Bearing, Radial Ball, 1-1/4 in Dia, Stainless Steel, Set Screw Locking
The NTN 2-Bolt Flange Bearing is a reliable and durable solution for applications requiring high-speed rotation and resistance to extreme temperatures. Its stainless steel housing and radial ball bearing insert provide exceptional corrosion resistance and smooth operation, while the double-sealed closure ensures long-lasting lubrication. Suitable for use in food processing, pharmaceutical, and other sanitary environments, this bearing is ideal for applications such as pumps, mixers, and conveyor systems. With a maximum speed of 4,300 RPM and operating temperatures between 14°F and 212°F, this bearing offers a wide range of applications in various industries.
Top product features:
- Double sealed closure for protection against contamination and debris
- Stainless steel bearing insert and housing for corrosion resistance and durability
- Fixed expansion type for secure fit and consistent performance
Top product applications:
- Pump Mounts
- Industrial Equipment Mounts
- Food Processing Equipment Mounts
2 Bolt Flange Bearing, Back Side to Center Width 0.709 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 1/4 in, Bore Type Cylindrical, Closure Double Sealed, Expansion Type Fixed, Housing Material Stainless Steel, Housing Type Rhombus, Included Bearing SUC206-20, Lubricant Material FDA/USDA-H1 Solid Grease, Maximum Speed 4,300 RPM, Maximum Temperature 212 Degrees F, Minimum Temperature 14 Degrees F, Mount Hole Center-to-Center Height 4 39/64 in
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.00
- Package Width: 4.30
- Package Height: 2.70
- Package Weight: 1.96
Product info last updated on March 29, 2026 4:43pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
