Take-up Bearing, 45mm SS MPN:SUCT209
Take-up Bearing, 45mm SS
The NTN Take-up Bearing is a reliable and durable solution for applications requiring radial ball bearings in extreme temperatures. Constructed with stainless steel housing and insert, this bearing is perfect for use in harsh environments where corrosion resistance is crucial. With a maximum temperature rating of 250°F and a minimum temperature rating of -4°F, it can withstand a wide range of operating conditions. Ideal for use in industrial equipment, machinery, and conveyor systems, this bearing provides smooth operation and long-lasting performance. Its compact design and fixed expansion type make it easy to integrate into existing systems.
Top product features:
- Double Sealed Closure
- Radial Ball Bearing Insert Type
- Set Screw Shaft Locking Type
Top product applications:
- Conveyor systems for food processing and pharmaceutical industries due to its corrosion-resistant stainless steel construction and ability to operate in a wide temperature range.
- High-temperature applications such as ovens, dryers, and heat exchangers where the bearing's maximum temperature rating of 250 Degrees F is a requirement.
- Automotive and industrial applications where a compact, sealed bearing is needed to support radial loads and provide smooth operation in a variety of environments.
Take-Up Bearing, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 45 mm, Closure Double Sealed, Expansion Type Fixed, Housing Material Stainless Steel, Included Bearing SUC209, Maximum Temperature 250 Degrees F, Minimum Temperature -4 Degrees F, Overall Height 144 mm, Overall Length 117 mm, Overall Width 49.2 mm, Rolling Element Rows 1, Shaft Locking Type Set Screws, System of Measurement Metric, Dynamic Load Capacity 5,778 lbf
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.30
- Package Width: 4.80
- Package Height: 2.20
- Package Weight: 5.42
Product info last updated on January 31, 2026 11:58pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
