Flange Bearing, 4-Bolt, Ball, 1-11/16" Bore MPN:UCF209-111D1
Flange Bearing, 4-Bolt, Ball, 1-11/16" Bore
The NTN 4-Bolt Flange Bearing is a reliable and versatile solution for various industrial applications. Suitable for use in harsh environments, this bearing features a double-sealed design and a maximum operating temperature of 250°F, making it ideal for high-temperature applications. With a maximum speed of 3,500 RPM, it can handle demanding rotational requirements. The bearing's fixed expansion type and cast iron housing ensure stability and durability. Its applications include machinery, equipment, and heavy machinery, particularly in industries such as manufacturing, construction, and oil and gas. It's available for immediate shipment in quantities of one or more.
Top product features:
- Double sealed closure provides a secure and protected environment for the bearing insert.
- Bearing insert is made of alloy steel for increased strength and durability.
- The bearing is a radial ball type, designed to support radial loads and provide smooth operation.
Top product applications:
- Conveyor systems
- Industrial machinery
- Heavy equipment
4 Bolt Flange Bearing, Back Side to Center Width 0.866 in, Bearing Insert Material Alloy Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 11/16 in, Bore Type Cylindrical, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Housing Type Square, Included Bearing UC209-111D1, Lubricant Material NLGI #3 Equivalent, Maximum Speed 3,500 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature -40 Degrees F, Mount Hole Center-to-Center Height 4 9/64 in
Additional Information
- Country of Origin: JP
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 8 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.00
- Package Width: 6.00
- Package Height: 2.50
- Package Weight: 4.90
Product info last updated on February 3, 2026 5:48am UTC
Category: Bearings, V-belts and Power Transmission Equipment
