4 Mount Holes, Square, 4 Bolt Flange Bearing, Radial Ball, 2 in Dia, Cast Iron, Set Screw Locking MPN:UCF211-200D1
4 Mount Holes, Square, 4 Bolt Flange Bearing, Radial Ball, 2 in Dia, Cast Iron, Set Screw Locking
The NTN 4-Bolt Flange Bearing is a reliable and durable solution for various industrial applications. Its 2-inch cylindrical bore and radial ball bearing design provide smooth operation and long lifespan. Suitable for use in temperatures ranging from -40°F to 250°F, this bearing is ideal for applications in heavy machinery, automotive, and construction equipment. Its double-sealed closure and alloy steel bearing insert ensure maximum protection against dust and moisture. With a maximum speed of 2,900 RPM, this bearing is perfect for high-performance machinery and equipment that require precise and efficient operation.
Top product features:
- Double sealed closure to protect against contamination and debris
- Fixed expansion type to provide stability and prevent movement
- Cylindrical bore diameter of 2 inches to accommodate specific applications
Top product applications:
- Industrial machinery
- Heavy equipment
- Pumps and compressors
4 Bolt Flange Bearing, Back Side to Center Width 0.984 in, Bearing Insert Material Alloy Steel, Bearing Insert Type Radial Ball, Bore Diameter 2 in, Bore Type Cylindrical, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Housing Type Square, Included Bearing UC211-200D1, Lubricant Material NLGI #3 Equivalent, Maximum Speed 2,900 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature -40 Degrees F, Mount Hole Center-to-Center Height 5 1/8 in, Number of Mount Holes 4
Additional Information
- Country of Origin: JP
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.70
- Package Width: 2.90
- Package Height: 6.70
- Package Weight: 7.80
Product info last updated on March 5, 2026 6:04pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
