4 Holes, Square Housing, 4 Bolt Flange Bearing, Radial Ball, 3/4 in Dia, Cast Iron, Set Screw MPN:UCF204-012D1
4 Holes, Square Housing, 4 Bolt Flange Bearing, Radial Ball, 3/4 in Dia, Cast Iron, Set Screw
This NTN 4-Bolt Flange Bearing is a reliable and versatile solution for various applications. Designed for radial ball bearing insert use, it features a 3/4in cylindrical bore and a cast iron housing with a square shape. The bearing is double sealed and can operate at temperatures ranging from -40°F to 250°F, making it suitable for a wide range of industries, including aerospace, automotive, and manufacturing. With a maximum speed of 6,700 RPM, it's ideal for high-speed applications, such as gearboxes, pumps, and conveyor systems. Its compact size and durable design make it a great choice for applications where space is limited.
Top product features:
- Fixed expansion type
- Double sealed closure
- Alloy steel bearing insert
Top product applications:
- Heavy Duty Industrial Equipment
- Pump Shafts
- Conveyor Systems
4 Bolt Flange Bearing, Back Side to Center Width 0.591 in, Bearing Insert Material Alloy Steel, Bearing Insert Type Radial Ball, Bore Diameter 3/4 in, Bore Type Cylindrical, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Housing Type Square, Included Bearing UC204-012D1, Lubricant Material NLGI #3 Equivalent, Maximum Speed 6,700 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature -40 Degrees F, Mount Hole Center-to-Center Height 2 33/64 in
Additional Information
- Country of Origin: JP
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.50
- Package Width: 3.60
- Package Height: 1.60
- Package Weight: 1.33
Product info last updated on February 28, 2026 8:07am UTC
Category: Bearings, V-belts and Power Transmission Equipment
