Pillow Block Bearing, Stainless Steel, Set Screw Locking, Ball Insert, 1-5/8 in Dia, Stainless Steel MPN:SUCPA209-26C0FG1
Pillow Block Bearing, Stainless Steel, Set Screw Locking, Ball Insert, 1-5/8 in Dia, Stainless Steel
This NTN pillow block bearing is designed for heavy-duty applications in food processing, pharmaceutical, and other industries where high sanitation standards are required. The stainless steel housing and FDA/USDA-H1 solid grease ensure cleanliness and prevent contamination. With a maximum temperature of 250°F and a minimum temperature of -4°F, this bearing can withstand extreme temperatures. Its radial ball design and double-sealed closure provide smooth operation and long lifespan. Suitable for use in conveyor systems, machinery, and equipment in the food, beverage, and chemical industries, this bearing offers reliable performance and easy installation.
Top product features:
- Radial ball bearing design provides stable and smooth rotation up to 3,100 RPM.
- Double sealed closure protects the bearing insert from contaminants and debris.
- Stainless steel housing and FDA/USDA-H1 solid grease ensure the bearing meets food-grade and high-sanitation standards.
Top product applications:
- Pump shaft support
- Conveyor belt support
- Machine tool spindle support
Pillow Block Bearing, Base Height 0.511 in, Base Width 2.007 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 5/8 in, Bore Type Cylindrical, Center Height 2 1/8 in, Closure Double Sealed, Housing Material Stainless Steel, Lubricant Material FDA/USDA-H1 Solid Grease, Maximum Speed 3,100 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Length 3 3/4 in, Mount Type Bolt-Through, Number of Mount Holes 2
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.62
- Package Width: 5.25
- Package Height: 3.31
- Package Weight: 5.14
Product info last updated on February 2, 2026 3:34am UTC
Category: Bearings, V-belts and Power Transmission Equipment
