Take-Up Bearing, 3/4" Bore, 3-11/16" L MPN:SUCT204-12C0FG1
Take-Up Bearing, 3/4" Bore, 3-11/16" L
This high-performance Take-Up Bearing from NTN is designed for demanding applications, featuring a stainless steel housing and insert for exceptional durability and resistance to corrosion. With a maximum speed of 5,900 RPM and temperature range of -4°C to 250°F, it's suitable for use in a wide range of industries, including food processing, pharmaceuticals, and chemical manufacturing. Its compact design and double-sealed closure ensure reliable operation and minimal maintenance. Ideal for applications requiring precise control and smooth motion, this take-up bearing is perfect for conveyor systems, textile machinery, and other equipment where precise movement is critical.
Top product features:
- Double sealed closure to protect against contamination and debris
- Stainless steel bearing insert and housing for corrosion resistance and durability
- Fixed expansion type allows for precise and secure fit to the shaft
Top product applications:
- Conveyor systems for high-temperature applications
- High-speed machinery in manufacturing environments
- Automotive and aerospace applications requiring high-speed and high-temperature performance
Take-Up Bearing Unit, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 3/4 in, Closure Double Sealed, Compatible Frame PWS100, Expansion Type Fixed, Housing Material Stainless Steel, Included Bearing SUC204-12FG1, Lubricant Material H-1 Food Grade Solid Lubricant, Maximum Speed 5,900 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature 24.8 Degrees F, Overall Height 3.503 in, Overall Length 3.7 in, Overall Width 1.75 in, Rolling Element Rows 1
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.05
- Package Width: 4.12
- Package Height: 2.55
- Package Weight: 1.85
Product info last updated on February 1, 2026 1:13am UTC
Category: Bearings, V-belts and Power Transmission Equipment
