Take-Up Bearing, 1-15/16" Bore, 5-3/4" L MPN:SUCT210-31C0FG1
Take-Up Bearing, 1-15/16" Bore, 5-3/4" L
The NTN Take-Up Bearing is a high-performance solution for various applications, including conveyor systems, textile machinery, and material handling equipment. Its stainless steel construction and radial ball bearing insert ensure durability and resistance to corrosion, while the double-sealed closure protects against contaminants and debris. With a maximum speed of 2,900 RPM and operating temperature range of -4°C to 250°F, this bearing is suitable for demanding industrial environments. Its compact size and set screw shaft locking mechanism make it easy to integrate into existing systems, providing reliable and efficient operation in a range of industries.
Top product features:
- Double sealed to prevent contamination and moisture ingress
- Fixed expansion type allows for precise control over bearing movement
- Set screws for shaft locking provide secure and adjustable retention
Top product applications:
- Pneumatic Conveying Systems
- Aerospace Equipment
- High-Temperature Industrial Applications
Take-Up Bearing Unit, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 15/16 in, Closure Double Sealed, Compatible Frame PWS200, Expansion Type Fixed, Housing Material Stainless Steel, Included Bearing SUC210-31FG1, Lubricant Material H-1 Food Grade Solid Lubricant, Maximum Speed 2,900 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature 24.8 Degrees F, Overall Height 4.606 in, Overall Length 5.866 in, Overall Width 3 in, Rolling Element Rows 1
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.62
- Package Width: 5.25
- Package Height: 3.31
- Package Weight: 5.91
Product info last updated on January 30, 2026 11:46pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
