Take-Up Bearing, 1" Bore, 3-3/4" L MPN:SUCT205-16CCFG1
Take-Up Bearing, 1" Bore, 3-3/4" L
The NTN Take-Up Bearing is a high-performance bearing designed for use in applications where flexibility and reliability are critical. With a stainless steel housing and insert, this bearing is ideal for use in harsh environments and can withstand temperatures from -4°C to 250°F. Its fixed expansion type and set screw shaft locking ensure precise control and stability. Suitable for use in a variety of industries, including food processing, pharmaceuticals, and chemical manufacturing, this bearing is perfect for applications where contamination and corrosion are a concern. Its compact design and high-speed capabilities make it an excellent choice for OEMs and machinery builders.
Top product features:
- Double sealed closure to prevent contamination and maintain bearing cleanliness
- Radial ball bearing insert for smooth and quiet operation
- Set screw shaft locking to secure the bearing in place
Top product applications:
- Conveyor systems for high-temperature applications
- Machine tool spindle bearings for metalworking machines
- High-speed packaging machinery components
Take-Up Bearing Unit, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 in, Closure Double Sealed, Compatible Frame PWS100, Expansion Type Fixed, Housing Material Stainless Steel, Included Bearing SUC205-16FG1, Lubricant Material H-1 Food Grade Solid Lubricant, Maximum Speed 5,100 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature 24.8 Degrees F, Overall Height 3.503 in, Overall Length 3.818 in, Overall Width 1.875 in, Rolling Element Rows 1
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.05
- Package Width: 4.12
- Package Height: 2.55
- Package Weight: 1.94
Product info last updated on February 1, 2026 12:12pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
