Pillow Block Bearing, Stainless Steel, Set Screw Locking, Ball Insert, 1-3/4 in Dia, Stainless Steel MPN:SUCP209-28C0FG1
Pillow Block Bearing, Stainless Steel, Set Screw Locking, Ball Insert, 1-3/4 in Dia, Stainless Steel
This stainless steel pillow block bearing from NTN is designed for heavy-duty applications in demanding environments. With a maximum temperature rating of 250°F and a minimum temperature rating of -4°F, it can withstand extreme temperatures and maintain performance. The bearing features a radial ball bearing insert and is lubricated with FDA/USDA-H1 solid grease, making it suitable for use in food processing, pharmaceutical, and other industries where cleanliness is critical. Its compact design allows for easy mounting and installation, and its high-speed capability makes it ideal for high-performance machinery and equipment.
Top product features:
- Radial ball bearing provides low-friction rotation
- Stainless steel housing resists corrosion
- FDA/USDA-H1 solid grease reduces lubricant contamination risk
Top product applications:
- Industrial conveyor systems
- Pumps and compressors
- Food processing equipment
Pillow Block Bearing, Base Height 0.787 in, Base Width 2.126 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 3/4 in, Bore Type Cylindrical, Center Height 2 1/8 in, Closure Open, Housing Material Stainless Steel, Lubricant Material FDA/USDA-H1 Solid Grease, Maximum Speed 3,100 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Length 5 47/64 in, Mount Type Bolt-Through, Number of Mount Holes 2
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.12
- Package Width: 7.00
- Package Height: 2.69
- Package Weight: 6.00
