Pillow Block Bearing, Stainless Steel, Set Screw Locking, Ball Insert, 1-1/4 in Dia, Stainless Steel MPN:SUCP206-20C0FG1
Pillow Block Bearing, Stainless Steel, Set Screw Locking, Ball Insert, 1-1/4 in Dia, Stainless Steel
This stainless steel pillow block bearing from NTN is designed for use in high-temperature and high-speed applications, with a maximum speed of 4,300 RPM and a temperature range of -4 to 250°F. The bearing features a cylindrical bore and a radial ball bearing insert, making it suitable for radial loads. Its compact design, with a base height of 0.708 in and a center height of 1 11/16 in, allows for easy installation in tight spaces. Ideal for use in food processing, pharmaceutical, and other sanitary environments, this bearing is a reliable choice for applications where cleanliness and durability are crucial.
Top product features:
- Radial ball bearing design provides stable support for rotational loads.
- Stainless steel housing resists corrosion and maintains durability in harsh environments.
- FDA/USDA-H1 solid grease lubricant ensures safe and sanitary operation in food processing applications.
Top product applications:
- Industrial Gearbox
- Pump Mounting
- Conveyor System
Pillow Block Bearing, Base Height 0.708 in, Base Width 1.889 in, Bearing Insert Material Stainless Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 1/4 in, Bore Type Cylindrical, Center Height 1 11/16 in, Closure Open, Housing Material Stainless Steel, Lubricant Material FDA/USDA-H1 Solid Grease, Maximum Speed 4,300 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature -4 Degrees F, Mount Hole Center-to-Center Length 4 3/4 in, Mount Type Bolt-Through, Number of Mount Holes 2
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.62
- Package Width: 5.25
- Package Height: 3.31
- Package Weight: 3.48
