Flange Bearing, 4-Bolt, Ball, 1-3/16" Bore MPN:UCF206-103D1
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0428364
Flange Bearing, 4-Bolt, Ball, 1-3/16" Bore
This NTN 4-Bolt Flange Bearing is a reliable solution for heavy-duty applications requiring high-speed operation and extreme temperature resistance. The bearing's alloy steel insert and double sealed design ensure long-lasting performance and protection against contamination. Suitable for use in industrial machinery, pumps, and gearboxes, this bearing can withstand temperatures from -40°F to 250°F and speeds up to 4,900 RPM. Its fixed expansion type and cast iron housing provide stability and durability. With a minimum order quantity of one, this bearing is ideal for maintenance and repair applications or for use in new equipment installations.
Top product features:
- Double sealed closure
- Radial ball bearing design
- Fixed expansion type
Top product applications:
- Pump shaft bearing
- Conveyor belt pulley bearing
- Gearbox bearing
4 Bolt Flange Bearing, Back Side to Center Width 0.709 in, Bearing Insert Material Alloy Steel, Bearing Insert Type Radial Ball, Bore Diameter 1 3/16 in, Bore Type Cylindrical, Closure Double Sealed, Expansion Type Fixed, Housing Material Cast Iron, Housing Type Square, Included Bearing UC206-103D1, Lubricant Material NLGI #3 Equivalent, Maximum Speed 4,900 RPM, Maximum Temperature 250 Degrees F, Minimum Temperature -40 Degrees F, Mount Hole Center-to-Center Height 3 17/64 in
Additional Information
- Country of Origin: JP
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.50
- Package Width: 2.00
- Package Height: 4.70
- Package Weight: 2.40
Product info last updated on February 12, 2026 2:29pm UTC
Category: Bearings, V-belts and Power Transmission Equipment
