Round 45 Degree Elbow, 9 in Duct Dia, Galvanized Steel, 22 ga GA, 14 1/2 in W, 16-1/2" L, 9 in H MPN:8040400006
Round 45 Degree Elbow, 9 in Duct Dia, Galvanized Steel, 22 ga GA, 14 1/2 in W, 16-1/2" L, 9 in H
This 45-degree elbow is a versatile ductwork component suitable for various ventilation and air handling applications. Its galvanized steel construction provides durability and resistance to corrosion, while the 22-gauge material thickness ensures a strong and reliable connection. With a maximum pressure rating of 42 inches of water column and a minimum pressure rating of 2 inches of water column, this elbow can handle a wide range of airflow demands. Its compact design allows for easy installation in tight spaces, making it an ideal choice for commercial and industrial settings, such as HVAC systems, ventilation systems, and air purification systems.
Top product features:
- Round shape allows for smooth airflow and reduced turbulence
- 45 degree angle enables efficient duct routing and reduced bends
- Clamp-together connection allows for easy assembly and disassembly
Top product applications:
- HVAC Systems for commercial buildings
- Industrial ventilation systems for factories and warehouses
- Air handling units for data centers and server rooms
45 Degree Elbow, For Nominal Duct Diameter 9 in, Material Steel, Overall Length 16 1/2 in, Product Type Elbow, Material Thickness 22 ga, Weight 7.6 lb, Maximum Pressure Rating 42 in wc, For Duct Height 9 in, Shape Elbow, End Type Rolled Edge, For Duct Width 9 in, Maximum Airflow Not Applicable, Inside Diameter 9 in, Minimum Pressure Rating 2 in wc, Color Silver, Outlet Diameter 9 in, Overall Height 9 in, Centerline Radius 1 1/2 in, Angle 45 Degrees , Connection Type Clamp Together
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.00
- Package Width: 12.80
- Package Height: 9.80
- Package Weight: 3.75
Product info last updated on February 9, 2026 3:13am UTC
Category: Ventilation
