Ball Spline Nut, 6 mm, 25 mm L MPN:SSPF 6
Ball Spline Nut, 6 mm, 25 mm L
This Ball Spline Nut from NIPPON BEARING is a versatile and reliable component suitable for a wide range of applications, including robotics, automation, and precision machinery. Its compact design and high load capacity make it an ideal choice for applications where space is limited and precision is crucial. The nut's carbon steel/resin construction provides excellent durability and resistance to wear and tear, while the oil hole ensures smooth operation. With a maximum operating temperature of 176°F, this nut can handle demanding environments and applications, including high-speed and high-load operations. It's an excellent choice for manufacturers seeking precision and reliability in their products.
Top product features:
- Ball Spline Nut has a lubrication oil hole for maintaining smooth operation.
- It has a dynamic load capacity of 5.1 N for supporting heavy loads.
- The nut features seals for protecting against contamination and extending lifespan.
Top product applications:
- Automotive applications
- Robotics and automation systems
- Medical devices and equipment
Ball Spline Nut, Inside Diameter 6 mm, Outside Diameter 14 mm, Flange Width Not Applicable, Overall Length 25 mm, Flange Diameter 30 mm, Dynamic Load Capacity 5.1 N, Flange Thickness 5 mm, Material Carbon Steel/Resin, Lubrication Oil Hole, Series SSPF, Static Load Capacity 40 N, Steady State Speed 2 mps, System of Measurement Metric, Maximum Operating Temperature 176 Degrees F, Minimum Operating Temperature Not Available, Bolt Size 1 mm, Includes Seals Seals Included, Body Width Not Applicable
Additional Information
- Country of Origin: JP
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 5 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.50
- Package Width: 1.50
- Package Height: 2.20
- Package Weight: 0.10
Product info last updated on February 1, 2026 7:44am UTC
Category: Bearings, V-belts and Power Transmission Equipment
