Bearing, 25mm, 34, 100 N, Steel, Snap-Ring MPN:5305MG
Bearing, 25mm, 34, 100 N, Steel, Snap-Ring
The MRC 25mm Angular Contact Ball Bearing is a high-performance bearing designed for demanding applications. Its 30-degree contact angle and two-row configuration provide exceptional load-carrying capacity and precision. Suitable for use in high-speed applications up to 10,000 RPM, this bearing can withstand temperatures from -20 to 125 degrees Celsius. Ideal for use in industrial machinery, robotics, and aerospace, this bearing offers improved efficiency, reduced maintenance, and increased productivity. Its compact size and lightweight design make it an ideal choice for space-constrained applications, while its steel cage and alloy steel construction ensure durability and long lifespan.
Top product features:
- Has an angular contact bearing type for increased load-carrying capacity and high precision operation.
- Can operate at a maximum speed of 10,000 RPM for high-performance applications.
- Has a temperature range of -20 to 125 degrees C for use in a variety of environments.
Top product applications:
- High-Speed Industrial Machinery
- Precision Medical Equipment
- Aerospace Applications
Angular Contact Ball Bearing, Bearing Industry Number 3305/5305, Bore Diameter 25 mm, Cage Material Steel, Closure Open, Contact Angle 30 Degrees , Contact Bearing Type Angular Contact, Matched Bearing Type Not Matched/Single Bearing, Maximum Speed 10,000 RPM, Maximum Temperature 125 Degrees C, Minimum Temperature -20 Degrees C, Number of Rows Two, Outside Diameter 62 mm, Overall Width 25.4 mm, Ring Material Alloy Steel, System of Measurement Metric, ABEC Rating 1
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.80
- Package Width: 3.00
- Package Height: 1.40
- Package Weight: 0.80
Product info last updated on February 1, 2026 6:40am UTC
Category: Bearings, V-belts and Power Transmission Equipment
