Bearing, 30mm, 46, 800 N, Steel, Double Seal MPN:5306MZZ
Bearing, 30mm, 46, 800 N, Steel, Double Seal
This 30mm angular contact ball bearing from MRC is a reliable solution for demanding applications. With a contact angle of 30 degrees and two rows of balls, it provides precise alignment and smooth operation in high-speed environments up to 6,300 RPM. The double seal design ensures long-lasting protection against dust and moisture, while the polyrex lubricant maintains optimal performance. Suitable for use in industrial machinery, robotics, and power transmission systems, this bearing supports heavy loads up to 800 N and withstands temperatures from -20 to 105°C. Its compact design and high-speed capabilities make it an ideal choice for applications requiring precision and reliability.
Top product features:
- Double sealed to protect against contamination and extend bearing life
- Angular contact design allows for high precision and rigidity in applications
- Polyrex lubricant provides long-lasting lubrication and reduces maintenance needs
Top product applications:
- High Precision Machinery
- High-Speed Electric Motors
- Heavy Duty Industrial Equipment
Angular Contact Ball Bearing, Bearing Industry Number 3306/5306, Bore Diameter 30 mm, Cage Material Steel, Closure Double Sealed, Contact Angle 30 Degrees , Contact Bearing Type Angular Contact, Lubricant Material Polyrex, Matched Bearing Type Not Matched/Single Bearing, Maximum Speed 6,300 RPM, Maximum Temperature 105 Degrees C, Minimum Temperature -20 Degrees C, Number of Rows Two, Outside Diameter 72 mm, Overall Width 30.2 mm, Ring Material Alloy Steel, Seal Type Contact
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 6 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.00
- Package Width: 3.00
- Package Height: 1.50
- Package Weight: 1.28
Product info last updated on February 4, 2026 9:32am UTC
Category: Bearings, V-belts and Power Transmission Equipment
