Bearing, 35mm, Double Shield and Snap-Ring MPN:5307CFFG
Bearing, 35mm, Double Shield and Snap-Ring
The MRC 35mm Double Shield and Snap-Ring Angular Contact Ball Bearing is a high-performance bearing designed for demanding applications. With a 30-degree contact angle and two rows of balls, it provides excellent load-carrying capacity and precision in high-speed operations. Suitable for use in gearboxes, pumps, and other machinery, this bearing offers improved efficiency and reliability. Its double-shielded design protects against contamination and extends lifespan. With a maximum speed of 7,500 RPM and operating temperatures ranging from -20 to 125 degrees C, it is ideal for use in harsh environments. Ideal for applications requiring high precision and reliability.
Top product features:
- Double shielded design provides protection from dust and contamination
- Polyrex lubricant maintains optimal bearing performance in a wide temperature range
- Angular contact bearing design allows for high-speed operation and precise positioning
Top product applications:
- High-precision machinery such as CNC machines and lathes
- Industrial equipment such as gearboxes and pumps
- Automotive applications such as wheel hubs and transmissions
Angular Contact Ball Bearing, Bearing Industry Number 3307/5307, Bore Diameter 35 mm, Cage Material Steel, Closure Double Shielded, Contact Angle 30 Degrees , Contact Bearing Type Angular Contact, Lubricant Material Polyrex, Matched Bearing Type Not Matched/Single Bearing, Maximum Speed 7,500 RPM, Maximum Temperature 125 Degrees C, Minimum Temperature -20 Degrees C, Number of Rows Two, Outside Diameter 80 mm, Overall Width 34.9 mm, Ring Material Alloy Steel, System of Measurement Metric
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 6 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.25
- Package Width: 3.25
- Package Height: 1.50
- Package Weight: 1.63
