Steam Trap, 3/4" NPT Outlet, SS Disc MPN:2E-SWG
Steam Trap, 3/4" NPT Outlet, SS Disc
The Mepco Steam Trap is a reliable and efficient solution for managing steam condensate in industrial applications. With a stainless steel disc and brass body, this steam trap is designed to withstand high temperatures and pressures, making it ideal for use in steam systems where condensate must be removed quickly and efficiently. Its straight-thru configuration and 3/4in NPT outlet ensure easy installation and reliable operation, while its condensate capacity of 2,450 lb/hr makes it suitable for a range of applications, including power generation, process heating, and HVAC systems.
Top product features:
- Straight-Thru configuration for unobstructed steam flow
- Air Vent included to prevent airlocks and ensure proper condensate drainage
- Stainless Steel disc for corrosion resistance and long product life
Top product applications:
- Steam Trap, Actuator Material Stainless Steel, Application Steam
- Steam Trap, Actuator Material Stainless Steel, Body Material Brass, Condensate Capacity 2,450 lb/hr, Application Condensate Return
- Steam Trap, Actuator Material Stainless Steel, Application Process Heating
Steam Trap, Actuator Material Stainless Steel, Application Steam, Body Material Brass, Condensate Capacity 2,450 lb/hr, Configuration Straight-Thru, Distance Between Inlet and Outlet Port 5 1/8 in, Includes Air Vent Air Vent Included, Inlet Port Connection Gender Female, Inlet Port Connection Size 3/4 in, Inlet Port Connection Type NPT, Installation Orientation Horizontal, Number of Ports 3, Operating Pressure - Maximum 25 psi, Operating Temperature - Maximum 345 Degrees F
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.90
- Package Width: 3.30
- Package Height: 3.40
- Package Weight: 2.00
Product info last updated on February 1, 2026 1:21am UTC
Category: HVACR and Appliance Controls
