Mini Barb Fitting, Al, 1 3/16 in L MPN:3/8BSPP-B6-O-AL
Mini Barb Fitting, Al, 1 3/16 in L
This compact aluminum mini barb fitting is perfect for chemical applications where a small, reliable connection is required. With a 3/8 inch pipe size and 1/4 inch tube inner diameter, it provides a secure connection for tubing and pipes. The beaded barb style ensures a leak-free seal, while the aluminum construction offers durability and corrosion resistance. Suitable for applications where high pressure and temperature are present, this fitting can withstand up to 125 psi and temperatures from -40°F to 230°F. Ideal for use in laboratories, chemical plants, and other industries where precise connections are crucial.
Top product features:
- It connects a 3/8 in pipe to a 1/4 in tube using a beaded barb style fitting.
- It is made from aluminum alloy 6061-T6 for durability and corrosion resistance.
- It has a maximum operating pressure of 125 psi and a temperature range of -40 to 230 Degrees F for safe use in chemical applications.
Top product applications:
- Chemical
- Chemical
- Chemical
MINI BARB FITTING, Fitting Side A Connection Type Male BSPP, Fitting Side B Connection Type Barbed, Fitting Side A Pipe Size 3/8 in, Fitting Side B Tube Inner Diameter 1/4 in, Barb Style Beaded, Fitting Material Aluminum, Material Grade 6061-T6, Overall Length 1 3/16 in, Specific Fitting Shape Straight Adapter, Application Chemical, Maximum Operating Pressure 125 psi @ 72 Degrees F, Maximum Operating Temperature 230 Degrees F, Minimum Operating Temperature -40 Degrees F, Thread Size A 3/8
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 17 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.00
- Package Width: 6.00
- Package Height: 1.00
- Package Weight: 1.00
Product info last updated on March 4, 2026 11:06pm UTC
Category: Pipes, Valves and Fittings
