Three-Phase General Purpose Motor, 150 HP, 447T Frame, 460V AC Voltage, 1190 rpm Nameplate RPM MPN:447TTDCD6077
Three-Phase General Purpose Motor, 150 HP, 447T Frame, 460V AC Voltage, 1190 rpm Nameplate RPM
General Purpose Motor, Three-Phase, Open Drip Proof Motor Enclosure Design, 150 HP, Nameplate RPM 1190 rpm, Frame 447T, Voltage 460V AC, 60 Hz Hz, Three Phase, Full Load Amps 173.0 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 95.4 Percent, Continuous Duty, 1,101-1,200
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 44.88
- Package Width: 39.25
- Package Height: 31.34
- Package Weight: 2075.00
Product info last updated on February 18, 2026 8:04am UTC
Category: Motors
