Three-Phase General Purpose Motor, 125 HP, 444T Frame, 460V AC Voltage, 1790 rpm Nameplate RPM MPN:444TTFCD6036
Three-Phase General Purpose Motor, 125 HP, 444T Frame, 460V AC Voltage, 1790 rpm Nameplate RPM
General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 125 HP, Nameplate RPM 1790 rpm, Frame 444T, Voltage 460V AC, 60 Hz Hz, Three Phase, Full Load Amps 140.0 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 95.4 Percent, Continuous Duty, 1701-1800, CSA Certified, UL Listed
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 66.00
- Package Width: 46.00
- Package Height: 32.00
- Package Weight: 1705.00
Product info last updated on January 27, 2026 3:51pm UTC
Category: Motors
