Single Function Time Delay Relay, Octal, On Delay, 1 Functions 24V AC/DC, DPDT MPN:TR-50228-05
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5268006
Single Function Time Delay Relay, Octal, On Delay, 1 Functions 24V AC/DC, DPDT
The Macromatic Single Function Time Delay Relay is a versatile and reliable solution for applications requiring precise timing control. With a single on-delay function, this octal-shaped relay can be used in a variety of settings, including industrial automation, medical equipment, and security systems. The relay's adjustable potentiometer allows for easy setting of delay times between 0.1 and 10 seconds, making it ideal for applications where precise timing is critical. Its compact design and plug-in mounting style make it easy to integrate into existing systems, providing a reliable and efficient solution for a wide range of applications.
Top product features:
- Adjustable time delay function with a minimum setting of 0.1 seconds and a maximum setting of 10 seconds
- On-delay functionality allows the relay to respond to input after a set time
- DPDT (double-pole double-throw) contact form provides a high current rating of 10 A at 240V AC or 30V DC
Top product applications:
- Automotive Lighting Systems
- Industrial Automation Control Systems
- Medical Equipment Control Systems
Single Function Time Delay Relay, Adjustment Method Potentiometer, Base Shape Octal, Coil Voltage 24V AC/DC, Contact Form DPDT, Contact Rating (AC) 10 A @ 240V, Contact Rating (DC) 10 A @ 30V, Current Rating 10 A, Number of Delay Functions 1, Delay Function On Delay, Electrical Connection Socket, Flat Pin Width Not Applicable, IP Rating IP20, Input Voltage 24V AC/DC, Minimum Time Setting 0.1 sec, Maximum Time Setting 10 sec, Number of Pins 8, Sealing Enclosed, Mounting Style Plug-In
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.60
- Package Width: 2.00
- Package Height: 4.10
- Package Weight: 0.25
Product info last updated on April 22, 2026 10:56am UTC
Category: Industrial Electrical Controls and Automation
